AODD Diaphragm Pump.
- Pump Material: Polypropylene
- Size: 1/2"
- Operating Temperature: -4 Celsius to +65C (24F to 149F)
- Non-Stall, Non-Freeze System
- Diaphragm Material: Santoprene
- Ball Material: PTFE
- Fluid Connection: BSP
- Air Inlet: 1/4" BSP
- Air Consumption: 25 CFM Max
- Displacement: 140CC
- Maximum Delivery: 15 Gallons per minute
- Made in Italy
Upgrade your current pump system to a reliable AODD pump capable of cold temperatures. These pumps are C1D2 safe and powered by compressed air.
This pump works with the Sambo Creeck Filtration Filter Trolley 400 and 630mm filtration system.
This is a replacement pump and whetted parts are rated to -4C.
Manifold configuration is CD. Custom configuration available upon request.
