Sanitary Clamp Hose Adapter

Safely Adapt Your Hoses With Our Trynox Sanitary Clamp Hose Adapter

This sanitary stainless steel fitting will help you connect, terminate, control and change the flow direction of your hygienic fluids operation.

Fits to sanitary stainless steel tubing
Surface finishing 180 Grit ID/150 Grit OD
Maximum operating pressure rating of 200 psi at 70 degrees Fahrenheit ambient temperature
Suitable for use in food, beverage, and other hygienic applications

Trynox Sanitary Clamp Hose Adapter is a well-priced, essential sanitary stainless steel item that you need in your hygienic fluids process. We have sanitary fittings that are available in threaded or unthreaded applications with multiple sizes and tube wall thicknesses. With wide range of high-quality sanitary stainless steel fittings and other sanitary fittings, your hygienic fluids operation is covered. Get our Trynox Sanitary Clamp Hose Adapter today.

SPECS:

Trynox TRHAC sanitary clamp hose adapter fitting
304 or 316L grade
.5”, .75”, 1”, 1.5”, 2”, 2.5”, 3” or 4” sizes

A-270 Sanitary Tubing Dimensional Tolerances

Tubing

A tube, or tubing, is a long hollow cylinder used for moving fluids (liquids or gases)

For Beverage & Sanitary stainless steel tubing for the Brewery, Food, Dairy and Pharmaceutical Industries must be manufactured in 304L & 316L polished on the ID to 20u-in Ra/OD to 30u-in Ra, Following standards like ASTM A-269; A-270, DIN 11805 or ENxxxxx

All dimensions in inches (mm)

Size OD	Wall Thickness	Outside Diameter	Length	Wall
1" (25.4)	0.065" (1.65)/0.049" (1.25)	+/-0.005 (0.13)	+1/8" (3.18)	- 0 +/-10.0%
1-1/2" (38.1)	0.065" (1.65)/0.049" (1.25)	+/-0.008 (0.20)	+1/8" (3.18)	- 0 +/-10.0%
2" (50.8)	0.065" (1.65)/0.049" (1.25)	+/-0.008 (0.20)	+1/8" (3.18)	- 0 +/-10.0%
2-1/2" (63.5)	0.065" (1.65)	+/-0.010 (0.25)	+1/8" (3.18)	- 0 +/-10.0%
3" (76.2)	0.065" (1.65)	+/-0.010 (0.25)	+1/8" (3.18)	- 0 +/-10.0%
4" (101.6)	0.083" (2.11)	+/-0.015 (0.38)	+1/8" (3.18)	- 0 +/-10.0%

Sanitary Gaskets General Performance Properties

	Nitrite (Buna)	Fluoro-Elastomer (Viton)	Platinum Cured Silicone Elastomer	Ethylene-Propylene Diene Monomer(EPDM)	PolyTetra Fluoro Ethylene(Teflon)	Tufsteel
Letter Designation	U	SFY	PX	EPDM	G	GTS
Sanitary Gasket Color Code	RED	Yellow & White	Pink	Green	Remains White	Remains Grey
Max Temperature Intermittent	240 F	410 F	580 F	300 F	450 F	578 F
Max Temperature Continuous	210 F	380 F	490 F	260 F	400 F	526 F
Minimum Temperature	-65	-20	-85	-70	-350	-370
USP Class VI	No	Yes	Yes	Yes	Yes	Yes
Steam in Place Performance	Poor	Good	Good	Good	Good	Excellent
Acids, Dilute	Good	Excellent	Good	Good	Excellent	Excellent
Alkalies	Good	Good	Excellent	Excellent	Excellent	Excellent
Alcohol, Glycols	Excellent	Good	Excellent	Excellent	Excellent	Excellent
Animal Oils & Fats	Excellent	Excellent	Good	Fair	Excellent	Excellent
Soaps, Bleaches, Detergents	Fair/Good	Good	Fair	Excellent	Excellent	Excellent
Vegetable Oil	Excellent	Excellent	Excellent	Fair	Excellent	Excellent
Water	Good	Excellent	Good	Excellent	Excellent	Excellent
