Trichome Pump AODD 1.5" Polypropylene 44 GPM P170

Trichome Pump AODD 1.5" Polypropylene 44 GPM P170

Regular price $1,350.00
Regular price $2,130.00 Sale price $1,350.00
Sale Sold out
Shipping calculated at checkout.
Request Quote

Dual Diaphragm pump for pumping delicate solids such as botanical trichomes. This pump was designed specifically to handle solids. This is the world's first purpose-built pump for Botanical Trichomes. You can move water quickly with this pump without fear of damaging trichomes due to shear, pressure, or temperature. This pump is made of food-grade plastics for the safe handling of the fluid.

Why is this pump special? Watch the discussion here.

Read the pump study here.

AODD Diaphragm Pump.

  • Pump Material: Food Grade Polypropylene
  • Size: 1.5"
  • Fluid Connection: 1.5" Sanitary Triclamp
  • Operating Temperature: -4 Celsius to +65C (24F to 149F)
  • Diaphragm Material: Santoprene + PTFE
  • Ball Material: PTFE
  • Air Inlet: 1/2" BSP
  • Air Consumption: 18 CFM Max
  • Maximum Solids Passing: 7.5mm
  • Displacement: 700CC
  • Maximum Delivery: 44 Gallons per minute
  • Maximum Head: 80m
  • Maximum Suction Dry: 5m
  • Maximum Suction Wet: 9.8m
  • Made in Italy


  • Length A: 18"
  • Width B: 9"
  • Height C: 16"

Cart with Pump Dimensions:

  • Length: 32"
  • Width: 10"
  • Height: 21"
