OSN Membrane Nano Filtration Solvent Recovery & Winterization System Basic Batch Mode

OSN Membrane Nano Filtration Solvent Recovery & Winterization System Basic Batch Mode

Regular price $69,000.00
Regular price $70,000.00 Sale price $69,000.00
Sale Sold out
Shipping calculated at checkout.
Size

Nano-filtration membrane system for non-thermal solvent recovery, winterization, and terpene isolation. Eliminate the need for a falling film evaporator or other similar equipment, as well as chillers and freezers for cryo extraction and winterization. Our systems are sized for any facility scale so you can run your extraction process without bottlenecks. Reduce your operating costs with our efficient solvent recovery systems.

The duplex model allows both winterization/remediation and solvent recovery in one machine.

Applications:

  • Non-Thermal Solvent Recovery
  • Winterization:
    • Remove Lipids & Waxes
    • Remove Gums and Phospholipids
    • Remove Water Soluble compounds
    • Remove Sugars
  • Color Remediation
  • Terpene Isolation
  • Sugar Removal

Features:

  • As low as 1 Cent (USD) or less per Gallon of clean solvent processed.
  • Up to 60 Gallons Per Hour permeation in ethanol.
  • Compatible with all 2540 membranes.
  • Low Membrane replacement costs. Long membrane life.
  • Pressures up to 1000 psi and cross-flow up to 9 GPM.
  • Can operate 1-4 membranes.
  • All stainless and Viton construction.
  • UL listed components.
  • C1D1 Compliant

Specification:

  • Power:
    • 2.5: 19A/230V/3PH, 9.5A/460V/3PH, 47A/230V/1PH
    • 4: 30A/460V/3PH
  • Dimensions: 53" x 31" x 43"
  • Weight: 430 Lbs.
